Solar panels

Retail price
0.0
Yuan
Market price
0.0
Yuan
Number of views:
1000
Product serial number
Category
Solar panel
Quantity
-
+
Stock:
0
1
1/1
Number of views:
1000
Product description
Monocrystalline Solar Panel
NO. Watts(W) Voltage(V) Solar panel size(mm) Solar Cell Quantiy/carton(pcs) Weight/piece(KG)
cell size configuration quantity
1 11 6 230*340*17*17 156.75*31 2*6 10 0.85
2 13 6 230*340*17*17 156.75*37 2*6 10 0.87
3 17 6 350*350*18*18 156.75*47 2*12 10 1.3
4 20 6 360*450*18*18 156.75*57 2*12 10 1.6
5 22 6 360*450*18*18 156.75*62 2*12 10 1.65
6 30 18 510*435*25*20 156.75*31 3*12 5 2.4
7 40 18 670*445*30*25 156.75*39 4*9 5 2.97
8 50 18 670*535*30*25 156.75*47 4*9 5 3.65
9 60 18 670*640*30*25 156.75*57 4*9 5 4.2
10 70 18 670*715*35*25 156.75*67 4*9 4 4.7
11 80 18 670*760*35*25 156.75*73 4*9 4 5.05
12 90 18 670*840*35*25 156.75*83 4*9 4 5.85
13 100 18 670*940*35*25 156.75*92 4*9 4 6.52
14 110 18 670*1020*35*25 156.75*104 4*9 4 6.6
15 120 18 670*1135*35*25 156.75*117 4*9 4 7.5
16 130 18 670*1210*35*25 156.75*120 4*9 4 7.9
17 150 18 670*1360*35*25 156.75*72 4*18 4 8.78
18 170 18 670*1480*35*25 156.75*156.75 4*9 4 10.55
19 200 18 992*1265*40*35 156.75*94 6*12 2 13.8
20 220 36 992*1320*40*35 156.75*104 6*12 2 14.2
21 300 36 992*1640*40*35 156.75*156.75 6*10 2 16.7
22 360 36 992*1950*40*35 156.75*156.75 6*12 2 20

Product description


-High efficiency crystalline solar cell; Long lifetime span: 25 years;
-Less power decrease: Decrease in peak power of the solar modules shall be below 8% within the first 10 years and within the first 20 years shall be below 10%;
-Advanced surface texturing process increases light absorption and efficiency;
-Sealed modules with tempered glass, high transmit rate and strong mechanical resistance; EVA resin, and a waterproof film, plus aluminum frame for extended outdoor use.



Solar Cells
> High Efficiency Solar Cells
> Appearance Consistency
> Color sorting ensure consistent appearance on each module
> Anti-PID

Front Glass
> 3.2mm Antireflective glass
> Translucency of normal luminance is increased by 2%
> Module efficiency is increased by 2%
> Self-cleaning function
> Service life is as long as 25 years (30 years optional)

Frame
> Conventional frame
> Silver or black frames are optional
> Boost bearing capability and prolong service life
> Serrated-clip design tensile strength

Junction Box
> Conventional standalone edition and engineering



DC voltage stable output; High conversion rate, high efficiency output; Weak light effect; Using toughened glass with high light transmittance; Durable anodized aluminum frame; Avoid freezing and deformation of water in the frame; The components are beautiful, strong and weather-resistant, easy to install.
